Our new carbon road bike disc brake clincher rims are 40~70 gram lighter than rim brake version, by using a new fiber layup that removes unnecessary excess material on the disc brake rims to save weight without compromising the rims strength, and constructed with premium Toray T700 & T800 carbon fiber.

All carbon rims are 100% customizable at Carbonal bike. Such as rim graphics, color painting, no rim-bed-hole tubeless, schrader or presta valve hole, internal nipple hole, reinforced rim, 2:1 lacing, G3 pattern, and customize rim mold (OEM).

700C Road bike 18mm internal width clincher rims:

Key points: Road / 18mm internal / clincher (tubeless ready) / tire size: 21C-38C recommended.

When a road bike racer is looking for perfect versatility. The new road disc brake carbon bicycle clincher rims range is the perfect answer with the best blend of lightweight, aerodynamic, high stiffness and great strength to deliver the highest possible efficiency.

700C Road/Gravel bike 21mm internal width clincher rims:

Key points:  Road / Gravel / 21mm internal / clincher (tubeless ready) / tire size: 23C-43C recommended.

***Rims D21-60 / D21-80 are sold exclusively by a customer in the UK. If you are from the UK, we are temporarily unable to provide this model for you, please understand!

700C Road/CX/Gravel bike 22mm internal width clincher rims:

Key points:  Road / CX / Gravel / 22mm internal / clincher (tubeless ready) / asymmetrical / tire size: 23C-50C recommended.

With a hooked bead and an internal width of 22mm, these rims can run anything from the super low presures for gravel, right up to high pressure when the ride turns to pavement. Available both symmetric and asymmetric rim profiles, and keeping the internal rim width at 22mm, means that you don't lose compatibility with thinner 25mm tyres, or even 23mm. It delivers on performance, handling, durable...pretty much everything really.

700C Road Racing bike 23mm internal width clincher rims:

Key points: Road / Performance / 23mm internal / clincher (tubeless ready) / tire size: 25C-50C recommended.

Crafted from ultra-light carbon fiber, the MG series rims are the result of continuous optimization in carbon fiber stacking technology. The use of high-quality T1000 and T800 carbon fiber materials ensures exceptional strength-to-weight ratio, making it an ideal choice for professional cyclists seeking maximum performance and durability.

700C Road/Gravel bike Wave 23mm internal width clincher / 24mm internal width hookless rims:

Key points: Road / Gravel / Performance / Wave / 23mm & 24mm internal / clincher & hookless (tubeless ready) / tire size: 25C-50C recommended.

The new special wave-shaped rim, designed for the ultimate performance. With an inner width of 23mm and rims height of 32/35mm, 35/40mm, 40/45mm, 45/50mm, 60/65mm, this rim design delivers enhanced agility, rapid acceleration on inclines, and precise, responsive handling during descents.

700C CX/Gravel bike 24mm internal width clincher rims:

Key points:  Cyclocross / Gravel / 24mm internal / clincher (tubeless ready) / tire size: 27C-50C recommended.

700C Road/CX/Gravel bike 22mm/24mm / 25mm internal width HOOKLESS rims:

Key points:  Road / CX / Gravel / Hookless (tubeless ready) / tire size: 23C-50C recommended.

700C CX/Gravel bike 29mm internal width clincher & 30mm internal hookless rims:

Key points: 700c (29") / Gravel / CX / 29mm internal clincher (tubeless ready) / 30mm internal hookless (tubeless ready) / tire size: 35C-65C recommended.

650b Road/CX/Gravel bike 22mm/ 24mm / 25mm internal width Clincher & HOOKLESS rims:

Key points:  650b (27.5") / Road / CX / Gravel / Hookless (tubeless ready) / tire size: 23C-50C recommended.

The advantage of disc brake clincher rims:

*Constructed with premium Toray T700 & T800 carbon fiber, super lightweight;

*Aerodynamic profile design;

*Easy tire mount and tubeless ready;

*5 years warranty.
